TECHNICAL DATA
Supply voltage
12 ÷30 Vdc (polarity protected)
Power consumption
max. 0,7W
Accuracy
± 0.5 °C (electronic section temperature -10÷50 °C)
Electronic board input Pt100
± 2 °C (electronic section temperature -10÷50 °C)
Electronic board input thermocouple
Output
Transistor PNP
Output NPN on request
refresh interval 1 second
max. pilot current 100 mA (with short-circuit protection)
Transistor NPN
Range configurations
It is possible set the device by EVOSTOPSET configuration kit (it is needed a PC with OS Windows).
PCB operating temperature
-25 ÷80°C
Sensing element operating temperature range (Pt100)
-100 ÷500°C
Sensing element operating temperature range (Thermocouple)
0 ÷1100 °C
Resolution
Pt100
0,1 °C
Thermocouple
1 °C
Connector
Male M12 x 1 in accordance with VDE0627 (output)
Sensing part connector
4-pin female connector with M12x1 metal screw lock (in accordance with DIN-VDE0627 STANDARDS)
Ambient tightness degree (*)
(*) in accordance with IEC 60529
IP67
