8,5 ÷32 Vdc (polarity protected)
maximum value between ±0.2 °C and ±0.2% of range set
Response time of electronics section
Effect of temperature (*)
Maximum value between ±0,3°C/25°C and ±0,3% of span/25°C
700 O @ 24 Vcc [RLO= (Valim. - 8,5) / 0,022]
RTD Pt100 (a= 0,00385) 3 wire connection
Sensor failure signalling
downscale (< 3.6 mA) action
Sensor short circuit signalling
Fixed at lower limit of range (< 3.6 mA)
It is possible set the device by EVOMINI+SET configuration kit (it is needed a PC with OS Windows).
any value between -50°C and +50°C
50°C (if the zero point is one of these values: -40°C, -20°C, 0°C, 20°C, 40°C, the minimum span is 20°C, otherwise is 50°C)
Sensor error compensation
over 2 points (max 1% of span)
range 0 ÷ 150°C / sensor break monitoring: > 21 mA (Upscale action)
